B16 (PSS10) - Suspension Kit - Bilstein - 48-349949
Details
Bilstein B16 (PSS10) suspension kits feature ride height adjustability with 10-stage manually adjustable dampers in an OE quality direct fit package. The 10-stage damping system adjusts both rebound and compression with each click to provide the best handling performance in any condition. These kits offer monotube performance dampers with matched springs that are tuned for each specific application. The zinc coated and threaded body design will give you the flexibility to find the perfect ride height setting for your intended use while providing unsurpassed protection against the harshest road elements. B16 (PSS10) suspension kits are made in Germany and feature technology tested on the famed Nürburgring. Quick and easy damping level adjustment; Threaded body allows lowering of approximately 30mm to 50mm; Tested by our engineers under motorsport conditions
Finish: Dampers: Zinc Plated Front Clear Anodized Rear/Springs: BlueFront Main Spring Rate (lbs/in): 342
Front Main Spring Type: Linear
Front Tender Spring Rate (lbs/in): 79
Internal Design: Monotube
PartType: Suspension Kit
Prop 65 (Y/N): Y
Prop 65 - Short Label: WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Rear Main Spring Rate (lbs/in): 565
Rear Main Spring Type: Linear
Rear Tender Spring Rate (lbs/in): 79
Segment: Tuning
Series: B16 (PSS10)
Title: Bilstein Shock Absorbers
Detailed Fitment Results
| Year | Make | Model | Submodel | Body Type Name | Drive Type Name | Bed Length Inches | Fitment Notes |
|---|---|---|---|---|---|---|---|
| 2006 | Porsche | 911 | Carrera 4S / Carrera 4 | Front Lowered Height: 15-35mm; Rear Lowered Height: 15-35mm; Sport Version | |||
| 2007 | Porsche | 911 | Targa 4S / Carrera 4S / Turbo / Targa 4 / Carrera 4 | Front Lowered Height: 15-35mm; Rear Lowered Height: 15-35mm; Sport Version | |||
| 2008 | Porsche | 911 | Carrera 4S / Turbo / Targa 4 / Carrera 4 / Targa 4S | Front Lowered Height: 15-35mm; Rear Lowered Height: 15-35mm; Sport Version | |||
| 2009 | Porsche | 911 | Turbo / Targa 4S / Carrera 4S / Targa 4 / Carrera 4 | Front Lowered Height: 15-35mm; Rear Lowered Height: 15-35mm; Sport Version | |||
| 2010 | Porsche | 911 | Targa 4S / Turbo / Carrera 4S / Carrera 4 / Targa 4 | Front Lowered Height: 15-35mm; Rear Lowered Height: 15-35mm; Sport Version | |||
| 2011 | Porsche | 911 | Turbo S / Carrera 4 / Carrera 4S / Targa 4S / Targa 4 / Turbo | Front Lowered Height: 15-35mm; Rear Lowered Height: 15-35mm; Sport Version | |||
| 2012 | Porsche | 911 | Carrera 4 / Turbo / Carrera 4 GTS / Targa 4S / Turbo S / Targa 4 / Carrera 4S | Front Lowered Height: 15-35mm; Rear Lowered Height: 15-35mm; Sport Version | |||
| 2013 | Porsche | 911 | Turbo / Turbo S | Front Lowered Height: 15-35mm; Rear Lowered Height: 15-35mm; Sport Version |
Fitments
- 2006 Porsche 911 3.6L GAS
- 2006 Porsche 911 3.8L GAS
- 2007 Porsche 911 3.6L GAS
- 2007 Porsche 911 3.8L GAS
- 2008 Porsche 911 3.6L GAS
- 2008 Porsche 911 3.8L GAS
- 2009 Porsche 911 3.6L GAS
- 2009 Porsche 911 3.8L GAS
- 2010 Porsche 911 3.6L GAS
- 2010 Porsche 911 3.8L GAS
- 2011 Porsche 911 3.6L GAS
- 2011 Porsche 911 3.8L GAS
- 2011 Porsche 911 4.0L GAS
- 2012 Porsche 911 3.4L GAS
- 2012 Porsche 911 3.6L GAS
- 2012 Porsche 911 3.8L GAS
- 2013 Porsche 911 3.4L GAS
- 2013 Porsche 911 3.8L GAS
