  • Chevrolet, GMC (2.7, 5.3 - 4WD) Transfer Case Assembly - N/A - Zumbrota Drivetrain - RTC3015G-2M

Chevrolet, GMC (2.7, 5.3 - 4WD) Transfer Case Assembly - N/A - Zumbrota Drivetrain - RTC3015G-2M

(0)No Reviews yet
SKU: RTC3015G-2M
BRAND: Randy's Worldwide : Zumbrota Drivetrain
$3,822.04 CAD
This item has a core charge of $875.00. Learn more about core charges



Details

Transfer Case

RTC3015G-2M

MP3015; Electric Shift, Shift motor is included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295

,MP3015,Electric,Shift,a,new,Shift,motor,is,included,Single,Speed,32,spline,Input,32,Spline,Rear,Output,External,Spline,Front,Output,Autotrack,Option,NP0,Tag,Numbers,84477163,84554627,84604685,84862540,84888174,84945265,84978149,85059483,85580977,Hollander,Number,412-10134,412-10295

Reman MP3015 T-Case, 2019-2024 GM 1500 Truck, W/ 8 Speed Auto, W/ Shift Motor

Remanufactured MP3015 Transfer Case, 2019-2024 GM Silverado 1500 and Sierra 1500, W/ 8 Speed Automatic, With Shift Motor

Zumbrota Drivetrain Transfer Cases are rebuilt to unparalleled standards for confidence and satisfaction driving behind the wheel. Our expert craftsmen take pride in restoring each unit to ensure the utmost quality by diligently executing each step. Cases and internal components are thoroughly inspected and tested for signs of wear such as cracks, stripped threads, shaft straightness, gear wear and chain stretch. Zumbrota uses an exclusive Hydro-blast rinse and blasting procedure on internal and external parts, followed by a proprietary shot-enticed deep cleaning. Each unit is fully rebuilt with replacement of all bearings, seals, and viscous couplers. All finished units are thoroughly spun tested for shift-ability and noise. All transfer cases are shipped in high density plastic totes to eliminate damage in transit.

Fits 2019-2024 GM 1500 Series Trucks

8 Speed Automatics

32 spline input

32 spline rear output

Shift motor is included

Spin tested for shiftability and noise

High-density plastic shipping totes eliminate in-transit damage

  • Fits 2019-2024 GM 1500 Series Trucks
  • 8 Speed Automatics
  • 32 spline input
  • 32 spline rear output
  • Shift motor is included
  • Spin tested for shiftability and noise
  • High-density plastic shipping totes eliminate in-transit damage
California Proposition 65: WARNING: This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Height: 18
Housing Color: Aluminum
Housing Material: Aluminum
Length: 34
Mounting Bracket Included: No
Rear Output Type: Slip Yoke
Selector Switch Positions: 3 Positions
Shift Operation Type: Electric
Transfer Case Fluid Capacity: 1.6
Transfer Case Fluid Included: No
Transfer Case Fluid Type: Dexron VI ATF
Transfer Case Manufacturer Code: NP0
Transfer Case Motor Included: No
Weight: 90
Width: 24

Detailed Fitment Results
YearMakeModelSub ModelBody TypeDrive TypeBed Length (in)Fitment Notes
2019ChevroletSilverado 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2019GMCSierra 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2020ChevroletSilverado 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2020GMCSierra 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2021ChevroletSilverado 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2021GMCSierra 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2022ChevroletSilverado 1500 LTD4WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2022ChevroletSilverado 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2022GMCSierra 1500 Limited4WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2022GMCSierra 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2023ChevroletSilverado 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2023GMCSierra 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2024ChevroletSilverado 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295
2024GMCSierra 15004WDMP3015; Electric Shift, Shift Motor is Included, Single Speed, 32 spline Input, 32 Spline Rear Output, External Spline Front Output, Autotrack Option NP0, Tag Numbers: 84477163, 84554627, 84604685, 84862540, 84888174, 84945265, 84978149, 85059483, 85580977, Hollander Number: 412-10134, 412-10295

Fitments

  • 2019 Chevrolet Silverado 1500 2.7L GAS
  • 2019 Chevrolet Silverado 1500 5.3L FLEX
  • 2019 Chevrolet Silverado 1500 5.3L GAS
  • 2019 GMC Sierra 1500 2.7L GAS
  • 2019 GMC Sierra 1500 5.3L FLEX
  • 2019 GMC Sierra 1500 5.3L GAS
  • 2020 Chevrolet Silverado 1500 2.7L GAS
  • 2020 Chevrolet Silverado 1500 5.3L FLEX
  • 2020 Chevrolet Silverado 1500 5.3L GAS
  • 2020 GMC Sierra 1500 2.7L GAS
  • 2020 GMC Sierra 1500 5.3L FLEX
  • 2020 GMC Sierra 1500 5.3L GAS
  • 2021 Chevrolet Silverado 1500 2.7L GAS
  • 2021 Chevrolet Silverado 1500 5.3L FLEX
  • 2021 Chevrolet Silverado 1500 5.3L GAS
  • 2021 GMC Sierra 1500 2.7L GAS
  • 2021 GMC Sierra 1500 5.3L FLEX
  • 2021 GMC Sierra 1500 5.3L GAS
  • 2022 Chevrolet Silverado 1500 LTD 2.7L GAS
  • 2022 Chevrolet Silverado 1500 LTD 5.3L FLEX
  • 2022 Chevrolet Silverado 1500 LTD 5.3L GAS
  • 2022 Chevrolet Silverado 1500 2.7L GAS
  • 2022 Chevrolet Silverado 1500 5.3L GAS
  • 2022 GMC Sierra 1500 Limited 2.7L GAS
  • 2022 GMC Sierra 1500 Limited 5.3L FLEX
  • 2022 GMC Sierra 1500 Limited 5.3L GAS
  • 2022 GMC Sierra 1500 2.7L GAS
  • 2022 GMC Sierra 1500 5.3L GAS
  • 2023 Chevrolet Silverado 1500 2.7L GAS
  • 2023 Chevrolet Silverado 1500 5.3L FLEX
  • 2023 Chevrolet Silverado 1500 5.3L GAS
  • 2023 GMC Sierra 1500 2.7L GAS
  • 2023 GMC Sierra 1500 5.3L FLEX
  • 2023 GMC Sierra 1500 5.3L GAS
  • 2024 Chevrolet Silverado 1500 2.7L GAS
  • 2024 Chevrolet Silverado 1500 5.3L FLEX
  • 2024 Chevrolet Silverado 1500 5.3L GAS
  • 2024 GMC Sierra 1500 2.7L GAS
  • 2024 GMC Sierra 1500 5.3L FLEX
  • 2024 GMC Sierra 1500 5.3L GAS
INSTALLATION: View Instructions
