  • Ram Transfer Case Assembly - N/A - Zumbrota Drivetrain - RTC4446D-12M

Ram Transfer Case Assembly - N/A - Zumbrota Drivetrain - RTC4446D-12M

(0)No Reviews yet
SKU: RTC4446D-12M
BRAND: Randy's Worldwide : Zumbrota Drivetrain
$5,241.59 CAD
This item has a core charge of $2,900.00. Learn more about core charges



Details

Transfer Case

RTC4446D-12M

BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift motor is included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD

BW4446 T-Case 19-24 Ram 4500/5500 DPL, AS66RC, R. Bolt Yoke, E-Shift, W/ Motor

Remanufactured BW4446/BW4448 Transfer Case, 19-24 Ram 4500/5500 With DPL Option, With Aisin Trans, Rear Bolt Yoke, Electric Shift, Shift Motor Included

Zumbrota Drivetrain Transfer Cases are rebuilt to unparalleled standards for confidence and satisfaction driving behind the wheel. Our expert craftsmen take pride in restoring each unit to ensure the utmost quality by diligently executing each step. Cases and internal components are thoroughly inspected and tested for signs of wear such as cracks, stripped threads, shaft straightness, gear wear and chain stretch. Zumbrota uses an exclusive Hydro-blast rinse and blasting procedure on internal and external parts, followed by a proprietary shot-enticed deep cleaning. Each unit is fully rebuilt with replacement of all bearings, seals, and viscous couplers. All finished units are thoroughly spun tested for shift-ability and noise. All transfer cases are shipped in high density plastic totes to eliminate damage in transit.

BW4446/BW4448 Transfer Case

28 Spline Input

Magnet wire in rear case

Rear Bolt on Yoke

8-Bolt Transmission Adapter

External Spline Front Output Shaft

Shift Motor is Included

  • BW4446/BW4448 Transfer Case
  • 28 Spline Input
  • Magnet wire in rear case
  • Rear Bolt on Yoke
  • 8-Bolt Transmission Adapter
  • External Spline Front Output Shaft
  • Shift Motor is Included
California Proposition 65: WARNING: This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Housing Color: Aluminum
Housing Material: Aluminum
Rear Output Type: Bolt On
Selector Switch Positions: 3 positions
Shift Operation Type: Electric
Transfer Case Fluid Capacity: 1.9
Transfer Case Fluid Included: No
Transfer Case Fluid Type: Synthetic TCF
Transfer Case Motor Included: Yes

Detailed Fitment Results
YearMakeModelBody TypeDrive TypeFitment Notes
2019Ram4500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2019Ram5500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2020Ram4500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2020Ram5500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2021Ram4500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2021Ram5500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2022Ram4500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2022Ram5500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2023Ram4500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2023Ram5500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2024Ram4500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD
2024Ram5500Cab & Chassis - Conventional Cab & Chassis - Crew Cab4 X 4BW4446; Electric Shift, 28 Spline Input, 8 Bolt Adapter Pattern, Rear Bolt Yoke, Exposed Front Output Shaft, With Option Code DPL 4.89 Axle Ratio, Shift Motor is Included, Tag Numbers: 68306997AA, 68306997AB, 68306997AC, 68306997AD

Fitments

  • 2019 Ram 4500 6.4L GAS
  • 2019 Ram 5500 6.4L GAS
  • 2020 Ram 4500 6.4L GAS
  • 2020 Ram 5500 6.4L GAS
  • 2021 Ram 4500 6.4L GAS
  • 2021 Ram 5500 6.4L GAS
  • 2022 Ram 4500 6.4L GAS
  • 2022 Ram 5500 6.4L GAS
  • 2023 Ram 4500 6.4L GAS
  • 2023 Ram 5500 6.4L GAS
  • 2024 Ram 4500 6.4L GAS
  • 2024 Ram 5500 6.4L GAS
INSTALLATION: View Instructions
