  • 2007.5-2018 Dodge Mega-Flo S-2 Flanged 6.7L Cummins Intake Manifold In Red - GDP 07511-MFS2-Red

2007.5-2018 Dodge Mega-Flo S-2 Flanged 6.7L Cummins Intake Manifold In Red - GDP 07511-MFS2-Red

(0)No Reviews yet
SKU: GLDP-07511-MFS2-Red
$558.59



Details

'07.5-'18 Mega-Flo S-3 6.7L Cummins Intake Manifold

Racing Applications Only

The Mega-Flo 6.7L intake manifold is a precision, permanent mold, aluminum casting. Casting via permanent mold and heat treating gives the Mega-Flo S-3 superior material density for final machining. The permanent mold process offers a precision part with a great finish for colored powdercoat.

To lower restriction even further we have gone to a 5 bolt mounting design. This design eliminates the pass thru boss needed for the 6th bolt and allows us to open the cross sectional area even further. Some 5 bolt manifold designs allow "gasket creep" which causes long term gasket failure due to thermal cycling. To eliminate this, we leave a gasket retainer boss for the 6th bolt location during final machining. This boss captures the gasket and eliminates gasket creep.

For accessories such as boost gauges, water/meth or nitrous the Mega-Flo S-3 is ready. On the back we have added five 1/8" NPT ports which will cover all of your additions with room to grow down the road.

All Mega-Flo S-3 6.7L intake manifolds include mounting bolts, gaskets, plugs, and full color instruction manual.

*Note for Twin Pump Applications: Only compatible with Fleece or ATS twin CP-3 kits at this time.

*Note: For race applications only

Fitments

2007_Dodge_Ram 2500_6.7L DIESEL, 2007_Dodge_Ram 3500_6.7L DIESEL, 2008_Dodge_Ram 2500_6.7L DIESEL, 2008_Dodge_Ram 3500_6.7L DIESEL, 2009_Dodge_Ram 2500_6.7L DIESEL, 2009_Dodge_Ram 3500_6.7L DIESEL, 2010_Dodge_Ram 2500_6.7L DIESEL, 2010_Dodge_Ram 3500_6.7L DIESEL, 2011_Ram_2500_6.7L DIESEL, 2011_Ram_3500_6.7L DIESEL, 2012_Ram_2500_6.7L DIESEL, 2012_Ram_3500_6.7L DIESEL, 2013_Ram_2500_6.7L DIESEL, 2013_Ram_3500_6.7L DIESEL, 2014_Ram_2500_6.7L DIESEL, 2014_Ram_3500_6.7L DIESEL, 2015_Ram_2500_6.7L DIESEL, 2015_Ram_3500_6.7L DIESEL, 2016_Ram_2500_6.7L DIESEL, 2016_Ram_3500_6.7L DIESEL, 2017_Ram_2500_6.7L DIESEL, 2017_Ram_3500_6.7L DIESEL, 2018_Ram_2500_6.7L DIESEL, 2018_Ram_3500_6.7L DIESEL
